| Place of Origin: | Shandong, China |
| Brand Name: | classiccnc |
| Price: | $26,000.00/Sets 1-2 Sets |
|---|---|
| Packaging Details: | The machine will be packed by the plywood case<br>China profile machining center VMC 1370 3-axis precision machining vertical CNC milling machine |
| Supply Ability: | 100 Set/Sets per Month |
| Condition: | New | Spindle Taper: | BT50 |
|---|---|---|---|
| No. Of Spindles: | Single | Type: | VERTICAL |
| Dimension(L*W*H): | 3800*3000*2650 | Weight (T): | 10 T |
| Table Size (mm): | 1500x700 | CNC Control System: | GSK, FANUC, KND, Siemens |
| Number Of Axes: | 3, 4 | Table Travel (X) (mm): | 1300 |
| Table Travel (Y) (mm): | 700 | Table Travel (Z) (mm): | 700 |
| Positioning Accuracy (mm): | 0.01 | Repeatability (X/Y/Z) (mm): | 0.004 |
| Range Of Spindle Speed(r.p.m): | 60 - 8000 R.p.m | Spindle Motor Power(kW): | 15 |
| Max. Table Load(kg): | 1000 Kg | Feed Speed(mm/min): | 10 - 10000 Mm/min |
| Rapid Feed Speed(m/min): | 36/36/20 | Min. Time Of Tool Change(s): | 2 |
| Tool Magazine Capacity: | 24 | Key Selling Points: | Automatic |
| Warranty: | 2 Year | Voltage: | 380V |
| Applicable Industries: | Hotels | Showroom Location: | Egypt, Turkey, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Morocco, Kenya, Argentina, South Korea, UAE, Colombia, Sri Lanka, Romania, Bangladesh, Sou |
| Marketing Type: | New Product 2021 | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 2 Years |
| Core Components: | Bearing | T Slot: | 5-18*120mm |
| X/Y/Z Axis Rapid Feed: | 36/36/20m/min | Tool Length: | 250/350mm |
| Spindle Nose To Table Surface: | 180-780mm | Machine Type: | CNC Vertical Machining Center |
| Product Name: | 3-axis Vertical Cnc Machining Center | Application: | General Machinery Processing |
| Product Type: | Cnc 3 Axis Machine | Name: | Vertical Machine Center CNC Machine |
| Processing: | Metal Cutting Cnc Milling Machine | Port: | Qingdao Or Shanghai Port |
|
Specifications
|
Units
|
VMC1370
|
|
Table size
|
mm
|
1400x700
|
|
X axis travel
|
mm
|
1300
|
|
Y axis travel
|
mm
|
700
|
|
Z axis travel
|
mm
|
700
|
|
Max. worktable load
|
kg
|
1400
|
|
T slot(number-width-pitch)
|
|
5-22x140
|
|
Max. spindle speed
|
rpm
|
8000(Optional:10000 )
|
|
Spindle taper
|
mm
|
BT50/BT40
|
|
Main motor power
|
kw
|
15/18.5
|
|
X/Y/Z rapid traverse speed
|
m/min
|
24/24/18
|
|
Cutting feed speed
|
mm/min
|
1-6000
|
|
Guide rail type
|
|
Linear rail
|
|
Distance from spindle axis to column surface
|
mm
|
780
|
|
Distance between spindle nose and worktable surface
|
mm
|
160-860
|
|
Positioning accuracy
|
mm
|
±0.0075
|
|
Repeat positioning accuracy
|
mm
|
±0.0075
|
|
Tool magazine
|
|
Arm 24
|
|
Max. tool diameter
|
mm
|
φ112 Adjacent)/ φ200(Apart)
|
|
Max.tool weight
|
kg
|
18
|
|
Machine weight
|
kg
|
10000
|
|
Overall dimension
|
mm
|
3870x3165x2920
|
